PRODUCT DESCRIPTION
The TH-365 is a dual-channel UV illuminance meter with a 365 nm narrow-band probe — the standard wavelength for UV curing and black-light inspection. Three ranges up to 19.9 mW/cm², memory functions and automatic shutdown make it a practical bench and field instrument.
Its 0.4 s sampling supports quick pass/fail checks of curing lamps and inspection lights across a production line.
SPECIFICATIONS
| Center Wavelength | 365 ±5 nm |
| Band | 320–400 nm |
| Measuring Ranges | 199 µW/cm², 1.99 mW/cm² and 19.9 mW/cm² |
| Accuracy | ±(2%FS + 2dgt) |
| Sampling | 0.4 s |
| Operating Temperature | 0–50°C |
| Weight | 375 g |
| Output / Communication | Direct probe measurement |
| Power Supply | DC 9V battery |
PRODUCT APPLICATION
The TH-365 UV illuminance meter is widely used in UV-source measurement, industrial inspection and laboratory use.
It is suitable for UV curing process control, fluorescent penetrant and magnetic-particle inspection, and laboratory UV exposure verification.
