PRODUCT DESCRIPTION
The TH-120-01H3 is an ultrasonic wind speed and direction sensor designed for integration into meteorological and environmental monitoring equipment. It is suitable for wind condition monitoring systems that require wind speed and wind direction data collection in outdoor environments. Based on its appearance, this model features a black cylindrical housing, a metal connection shaft on the top, a layered body structure, and fixed support details. It measures wind speed with 0.1 m/s resolution and ±3% accuracy, and wind direction with 0.1° resolution and ±3° accuracy.
With a compact structural design, the product can be installed in weather stations, environmental monitoring equipment, agricultural monitoring systems, or outdoor automation devices. Its aluminum alloy housing is rated IP65 and operates from -20 to +60°C and 0–100% RH, running on 5–30 V power with just 0.3 W consumption and RS485 output via a 5 m cable. The TH-120-01H3 can serve as a basic sensing component in wind monitoring systems and work with data loggers, controllers, or integrated weather monitoring systems to provide data support for on-site wind condition monitoring, environmental data analysis, and automated equipment control.
SPECIFICATIONS
| Sensor Type | Ultrasonic wind speed and direction |
| Wind Speed Resolution | 0.1 m/s |
| Wind Speed Accuracy | ±3% |
| Wind Direction Resolution | 0.1° |
| Wind Direction Accuracy | ±3° |
| Output / Communication | RS485 |
| Power Supply | 5–30 V |
| Power Consumption | 0.3 W |
| Protection Rating | IP65 |
| Material | Aluminum alloy |
| Cable Length | 5 m |
| Operating Temperature | -20 to +60°C |
| Operating Humidity | 0–100% RH |
PRODUCT APPLICATION
The TH-120-01H3 can be used in weather stations, environmental monitoring stations, smart agriculture systems, greenhouses, photovoltaic power stations, wind energy projects, roads, bridges, ports, docks, outdoor safety monitoring, and industrial automation monitoring.
It is suitable for monitoring equipment or systems that require integrated wind speed and direction detection. By helping users collect on-site wind condition data, it provides useful reference data for meteorological analysis, environmental management, equipment operation, safety warning, and automation control.
